FS-1200 Specification
yes
NetWare
Tested and
Approved
Your authorised KYOCERA distributor:
The 3 year on-site warranty extension for printer and options.
KYOCERA ELECTRONICS EUROPE GmbH, Mollsfeld 12, D - 40670 Meerbusch, Germany, Tel.: ++49 (0) 2159/918-0, Fax: ++49 (0) 2159/918-106, www.printer.kyocera.de
ECOSYS cartridge-free technology avoids the need to replace the drum and
developer, treated as consumables on conventional printers. Because the only
consumable is toner, printing costs are exceptionally low. ECOLaser Printers are
environmentally friendly as the only waste is the empty toner container which
can be recycled.
PRESCRIBE IIe: programming language with expanded graphics
functions. Forms capabilities in all system environments.
Emulations: PCL6 incl. PJL, PostScript II* (KPDL 2) with automatic
emulation sensing (AES), Diablo 630*, IBM Proprinter X24E*,
Epson LQ-850*, Lineprinter*.
Fonts: 80 bitmapped fonts and 80 scaleable fonts. 43 bar codes
(e.g. EAN 8/EAN 13/EAN 128) incl. two dimensional bar code PDF-417
support with automatic checksum generation.
Downloadable fonts: KYOCERA, PCL, type 1+3.
Standard interfaces: high speed bi-directional parallel port (IEEE 1284,
Windows95/98* compliant), option interface port.
Optional IB-10: RS-232C/RS-422A serial port (up to 115.200 Bps).
Optional SB-4e/SB-5ef/SB-6e/SB-100: Ethernet/Fiberlink-Ethernet/
TokenRing-/Fast Ethernet interface with multiprotocol support and SNMP for
NOVELL* (IPX) inclusive NDS, Unix* (TCP/IP), Apple EtherTalk/TokenTalk*.
Optional host interface for IBM Coax/Twinax/Fast Ethernet/
TokenRing with SCS and (optional) IPDS/AFP support from 3rd party.
MIC (Multiple Interface Connection) allows for simultaneous data
transfer via up to two interfaces, with each interface having its own
virtual printer.
KYOCERA PrintMonitor (KPM) offers convenient status control and
printer administration from each network PC; the FS-1200 supports the
SNMP protocol with MIB II.
PC/Jeida card: slot supports up to 16 MB maximum and is ideal for
printing forms, fonts and logos.
ECOmemory: memory compression and dynamic memory management.
Sleep mode: user definable period which reduces power consumption
and meets EnergyStar requirements.
ECOprint: for toner savings up to 50 %, ideal for draft quality documents,
copies etc.
E P A P O L L U T I O N P R E V E N T
!R!
Following network ready products are available: FS-1200/E12 (incl. Ethernet,
12 MB), FS-1200/F12 (incl. FastEthernet, 12 MB).
All paper capacities indicated refer to a maximum paper thickness of 0.1 mm max.
Be sure to use the print materials recommended by KYOCERA.
This printer is produced according to the quality norm ISO 9001 and the
environmental guidelines ISO 14001.
Engine KYOCERA ECOSYS-Type
1st page < 15 sec
Printing method Electrophotography using laser
technology
CPU PowerPC RISC processor/71 MHz
RAM 4 MB + ECOmemory
Maximum RAM 68 MB via 1 DIMM slot
(e. g. MD-8/8 MB, MD-16/16 MB,
MD-32/32 MB, MD-64/64 MB)
Print speed up to 12 ppm (A4)
Resolution 600 dpi, with KIR2 up to 2400 dpi
Duty cycle maximum 20.000 pages per month
Paper specification 60-135 g/m 2 OHP film, laser labels,
envelopes and postcards ≤ 200 g/m 2 .
Paper feed 250 sheet universal cassette 60-90 g/m 2
A4, A5, B5, Letter, Legal, Custom
(148x 210 mm to 216x 356 mm)
100 sheet multi-purpose tray
60-200 g/m
2 A6-A4
Paper output 250 sheets face down/face up
Paper options
Duplex unit DU-20/DU-21 Double-sided printing 60-135 g/m 2 A4,
B5, A5, Letter, Legal (max. 2 PF-20)
Paper feeder PF-20/PF-21 500 sheets 60-90 g/m 2 A4, B5, A5,
Letter, Legal (max. 2 PF-20)
Paper transport unit HS-20 required for DU-20/DU-21/SO-6/ST-20
Paper cassette TPC-21 250 sheets 90-135 g/m 2 A4
(replaces universal cassette)
Paper tray PT-4 250 sheets face up
Stacker ST-20 1.500 sheets face down
Sorter SO-6 1.250 sheets face down, in 15 trays,
incl. mailbox function
(15 x 50 + 1 x 500 sheets)
Toner kit TK-25 Microfine mono component ceramic
toner for 5.000 pages with 5% cover-
age/9000 pages with ISO 10561
(Dr. Grauert)
Power consumption printing 311 W
stand-by 105 W
sleeping 19 W
Noise printing 50 dBA
stand-by 39 dBA
sleeping 0 dBA
Power 220/240 V, 50/60 Hz
Dimensions (HxWxD) 310 x 373 x 383 mm
Weight 14 kg
Certification GS/TÜV, CE
DBE FS-1200/Rev
. 9/99 – printed on chlorine-free paper *All trade marks acknowledged. Specifications are subject to change. I
nfor
mation is correct at time of going to press.
Warranty:
2 years warranty as standard. KYOCERA guarantees the drum and developer
for 3 years or 100.000 pages (whichever occurs sooner), provided each printer
is used and cleaned in accordance with the service instructions.
FS-1200
PF-20/PF-21
PF-20/PF-21
DU-20/DU-21
PA-1
PA-20
HS-20
SO-6/ST-20
