Keys Fitness KF-ABM - Manual (Page 10)

10
KF-ABM Parts list Rev A
Ref # Part # description Qty
1 3-01051 FRAME, MAIN KF-ABM 1
3-0105 FRAME, SIDE KF-ABM 1
3 19-00440 PIVOT ARM, KPS-ABM 1
4 19-0018 CIRCULAR PLATE W/ AXLE KPS-ABM/BTM 1
5 19-0014 WEIGHT HOLDER KPS-LEGM 1
19-00498 SUPPORT, SEAT KF-ABM 1
7 19-00499 FRAME, FOOT KF-ABM 1
8 10-0057 POP PIN (LOCKING), KF-45/KF-AAB
9 10-0059 LONG POP PIN, KF-LEGM 1
10 3-01053 BASE, REAR KF-ABM 1
11 0-0001 BRONZE ID 5.4
1 0-00134 PLASTIC WASHER KPS-050/1850 1
13 0-0039 FOOT CAP, RIGHT 50.8 KF SERIES 3
14 0-00393 FOOT CAP, LEFT 50.8 KF SERIES 3
15 10-0010 STOPPER PRONE 1
1 0-00114 PLASTIC SLEEVE, 50.8x44.5 4
17 0-0043 PLASTIC TUBE FOR FOAM PAD,KPS-ABM 1
18 8-00078 LONG FOAM ROLLER KPS-ABM 1
19 0-00395 FOAM PADDING, 100XX180 KF SERIES
0 8-0041 PAD, SEAT KF-ABM 1
1 0-0018 PLUG 38 3
0-0000 PLUG 44.5 3
3 0-00391 SQUARE PLUG, 50.8 KF SERIES 3
4 0-00138 ROUND PLUG 5
5 0-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES
0-00033 BIG PLASTIC WASHER KPS, 4**3 1
7 0-00044 RUBBER SLEEVE KPS 1
8 0-00471 BUMPER, KF-ABM 1
9 19-00008 SPRING COLLAR 1
30 19-003 SPRING COLLAR PLASTIC GRIPS
31 19-00437 ROLLER TUBE, KPS-ABM 1
3 19-0035 COLLAR 1
33 0-0000 END CAP FOR SHAFT 1
34 0-0007 GRIP, 3X3X185
35 0-00458 GREASE FITTING, KPS-ABM 1
3 0-0055 PIVOT TENSION PIN 1
37 0-00143 SCREW, M8* 1
38 0-0037 SCREW, M10X70 BUTTON HEAD SOCKET CAP 1
39 0-0034 SCREW, M10X80 BUTTON HEAD SOCKET CAP 4
40 0-00 SCREW, BUTTON HEAD SOCKET CAP M10X5
41 0-003 SCREW, M8X5 BUTTON HEAD SOCKET CAP
4 0-003 WASHER, 11X3X 1
43 0-00094 WASHER 8, 9*8*
44 0-00091 NYLON NUT, M10 5
45 0-00133 HEX KEY 4 1
4 0-00703 HEX KEY 5 1
47 0-0013 HEX KEY 1
Parts list
