Parts list – Keys Fitness Alliance A7 Upright A7u User Manual
Page 19
Parts List
19
REF# KEYS PART#
DESCRIPTION
QTY. REF# KEYS PART#
DESCRIPTION
QTY.
A1 323-00165
A7u Frame Assembly
1
C10
302-00277
A7r & A7u Spring Washer SW8
9
A2
310-00123
A7r & A7u Water bottle Holder
1
C11
302-00245
A7u Hex Screw M6*1.25*50
4
A3
302-00311
A7u Seat post bolt
2
C12
302-00252
A7r & A7u Insert Nut M10*1.5
4
A5
331-00038
A7r & A7u Bearing
2
D1
323-00161
A7r & A7u Rear Stabilizer Assembly
1
X1
324-00001
A7r & A7u Bottom Bracket Set
1
E1
328-00023
A7u Seat
3
A11 311-00043
A7r & A7u Crank and Pulley set
1
E2
323-00167
A7u Seat post Assembly
3
A12 304-00017
A7u Poly-v Belt
1
E3
306-00321
A7u Sleeve
3
A13 330-00045
A7r & A7u Crank
1
E4
310-00125
A7u Locking Pop Pin Knob
1
A14 306-00311
A7r & A7u Pedal L & R
1
F1
302-00258
A7r & A7u Round Head Allen Bolt M5*0.8*12
1
A15
331-00039
A7r & A7u Bearing
3
F2
302-00278
A7r & A7u Spring Washer SW5
2
A16 330-00046
A7r & A7u Crank and Pulley Axle
1
F3
302-00231
A7r & A7u Flat Washer M5 (5.3*10*1)
1
A17 302-00218
A7r & A7u C Ring 25
1
F4
319-00005
A7r & A7u Axle Assembly Idler
3
X2
324-00002
A7r & A7u Poly of Second Axle Assembly
1
F5
302-00309
A7u C Ring 8
1
A22
302-00219
A7r & A7u C Ring 17
1
X3
324-00003
A7r & A7u Aluminum Idler Wheel Assembly
1
A23 307-00061
A7r & A7u Load Resister
2
F8
331-00045
A7r & A7u DU Bearing
1
A24
302-00228
A7r & A7u Flat Washer M5 (5.5*13*1)
14
F9
330-00044
A7u Idler Arm Assembly
2
A25 302-00263
A7r & A7u Round Head Screw M5*0.8*10
4
F10
302-00223
A7r & A7u C Ring 14
1
A26 302-00266
A7r & A7u Round Head Screw M5*0.8*15
19
F11
302-00275
A7r & A7u Spring
1
A27
302-00264
A7r & A7u Round Head Screw M4*0.7*10
4
G1
311-00044
A7r & A7u Generator
1
A28 302-00242
A7r & A7u Hex Nut M4*0.7
4
G2
302-00220
A7r & A7u C Ring 15
4
A29 313-00086
A7u Wire of Load Resister (B)
2
G3
331-00040
A7r & A7u Bearing (6002LLU)
4
A30
313-00085
A7u Wire of Load Resister (A)
1
G4
319-00007
A7r & A7u Generator Base
5
A31 307-00060
A7r & A7u Control Board Ver3.1
1
G5
306-00314
A7r & A7u Shielding Pad
5
A32 302-00243
A7r & A7u Hex Nut M6*1.0
2
G6
313-00081
A7u Output Generator Wire
4
A33 302-00308
A7r & A7u Sensor Cable Bracket
1
G7
302-00259
A7r & A7u Round Head Allen Bolt M5*0.8*30
4
A34 313-00089
A7u Sensor Cable
1
G8
302-00217
A7r & A7u Bushing 25*22
1
A35 302-00265
A7r & A7u Round Head Screw M3*0.5*8
2
G9
302-00233
A7r & A7u Flat Washer M8 (8.5*26*2.5)
1
A36
302-00268
A7r & A7u Round Head Screw M5*0.8*15
8
G10
302-00319
A7u Round Head Allen Bolt M8*1.25*55
1
A37 304-00013
A7u Poly-v Belt J6 762
1
G11
302-00260
A7r & A7u Round Head Allen Bolt M8*1.25*45
2
A38 302-00273
A7r & A7u Sensor Magnetic
1
H1
323-00166
A7u Pulse Handlebar Assy
1
A39
313-00088
A7u Lower Wire Hardness
1
H2
313-00078
A7r & A7u Heart Rate Sensor plate
2
B1
305-00054
A7u Right Shroud
1
H3
302-00271
A7r & A7u Round Head Screw M3*0.5*35
1
B2
305-00053
A7u Left Shroud
1
H4
306-00308
A7r & A7u Heart Rate Sensor Grip
6
B3
306-00319
A7u Decoration Cover
1
H5
302-00246
A7r & A7u Hex Nut M3*0.5
4
B4
306-00304
A7r & A7u Decoration Cap
8
H6
307-00059
A7r & A7u Console
1
C1 323-00159
A7r & A7u Front Stabilizer Assembly
1
H7
302-00225
A7r & A7u Flat Head Allen Bolt M8*1.25*16
1
C2
310-00122
A7r & A7u Adjusting Knob
4
H8
313-00090
A7u Upper Wire Hardness
1
C3
306-00306
A7r & A7u Foot Cap
4
H9
313-00087
A7u Heart Rate Sensor wire
1
C4
306-00310
A7r & A7u Leveling Base
4
H10
306-00322
A7u Console Tube Cover
1
C5
302-00244
A7r & A7u Hex Nut M6*1*40
2
H11
302-00310
A7u O Ring
8
C6
302-00229
A7r & A7u Flat Washer M6 (6.5*13*1)
4
H12
306-00320
A7u Grip for Front Handlebar
2
C7
302-00254
A7r & A7u Nylon Nut M6*1
2
H13
306-00307
A7r & A7u Handlebar End Cap
4
C8
306-00318
A7r & A7u Transportation Wheel 3*23
2
H14
323-00168
A7u Reading Rack
4
C9
302-00230
A7r & A7u Flat Washer 8.4*17*2
9
A7u Parts List Rev C
