Technical annex
Technical data
RF features
Sat-IF frequency range 950 to 2150 MHz
Input level range 43 to 83 dBµV
IF frequency 479,5 MHz
Receiving threshold (Eb/No dig.) £4,5 dB
Sat-IF input
F-socket with loop-through output
Input impedance 75 W
Video
Modulation, FEC, demultiplexer DVB-S-Standard
Video resolution CCIR 601 (720 x 576 lines)
Frequency range 20 Hz to 5 MHz
Input data rates 2-45 MSymbols/s
Video decoding MPEG-1/2-kompatibel
Bit rate 1,5-15 MB/s
Output voltage 1 V
ss
/ 75 W
S/N ³53 dB typ.
Audio
Audio decoding MPEG-1/2, layers 1 and 2
Bit rate 32/44,1/48 kb/s
Frequency range 40 Hz to15 kHz
Output voltage typ. 770 ± 50 mV at 10 kW (TV-Scart and Cinch)
S/N ³65 dB
Power supply
Mains voltage 230 V ±10%, 50 Hz
Power consumption <30 W
Power consumption in standby <9 W
LNB voltage supply 0, +14 V (vert.), +18 V (hor.)
LNB supply current 400 mA max.
Control signals 22-kHz-Rechteck 0,6 V
ss
Tone Burst
DiSEqC 1.1
UFOmicro
UFOmini
Connections
TV connection SCART socket, 21-pin
VCR/AUX connection SCART socket, 21-pin
Audio output 2 x Cinch socket
Dolby Digital output (AC3) Cinch-socket
Data interface for service purposes RS 232 Sub D 9-pin
General
Dimensions (W/H/D) 335 / 63 / 280 mm³
Weight approx. ca. 2,4 kg
Temperature range
Ambient temperature +5 °C to + 40 °C
