17
Attachments
Curl Bar Attachment
Attach the curl bar (31) to the leg lever (18) and secure by inserting the curl bar pin (28).
Note: You will need to remove the curl bar when using the leg extension.
28
18
31
Olympic Plate Adapter
To use olympic weights, press the 48mm round inner cap (38) into the olympic adapter (47).
Secure the olympic adapter (47) to the weight tube (19) using M8X10mm set screw (60).
Make sure the set screw (60) is on the bottom of the adapter. Secure the weight plates with
included large spring clip (not shown).
18
12
24
19
47
60
38
WARNING!
Do not place more than 150 pounds on the weight tube. Secure the weights with spring clips.
