Technical Specifications
Model #: KD-VA5
RGBHV-to-Component or Component-to-RGBHV Video Adapter
Analog Video Modes
RGBHV-to-Component (YPbPr) Video conversion
Also supports SCART RGB Video input
Component-to-RGBHV Video conversion
Auto Sensing
Intelligent Auto Sensing ™ automatically switches from RGBHV-to-Component Video or
Component-to-RGBHV Video by sensing active sync on the “Y” Component Video signal
If the Component Video input is connected with active sync on Y, the Intelligent Auto
Sensing ™ automatically forces the KD-VA5 to the Component-to-RGBHV Video Mode by
sensing active sync on the “Y” Component Video signal
If there is no YPbPr input (in particular, no sync on the “Y” channel), the unit automatically
selects the RGBHV-to-Component Video Mode
Sync Modes
Component Video with sync on “Y”
RGBHV Video with separate H & V sync
Additional sync modes supported:
RGB Video with “sync on green” (RGsB)
SCART input (RGB Video plus Composite Sync on H input)
Composite sync on H output
Pass-through
Allows connections to two display types:
RGBHV-to-Component (YPbPr) Video conversion drives the Component Video HD display,
while the RGBHV pass-through drives an RGBHV display
Component-to-RGBHV Video conversion drives the RGBHV display, while the Component
Video pass-through drives the Component Video HD display
›
➔
›
›
➔
➔
›
›
›
➔
➔
➔
›
›
›
Resolution
The output resolution = the input resolution
Performs no video processing
Compatible Video Signals
Supports most analog interlaced and progressive video formats, at 60 Hz or 50 Hz, like
HDTV, NTSC, and PAL:
1080i (60 & 50 Hz)
720p (60 & 50 Hz)
480p (60 Hz)
576p (50 Hz)
576i (50 Hz, SCART only)
Analog Video Characteristics
Output stage drives high-quality, equal-length video cables up to 50’
1V p-p @ 75 ohms, terminated
Composite video sync on “Y” input (YPbPr)
Video bandwidth:
-3 dB @ 150 MHz
Linear phase pass-band
Unity video gain
Each input of the KD-VA5 has its own 75 Ω termination
Do not daisy chain inputs
Connectors
RGBHV Input Port and Output Port are HD-15 VGA female connectors
YPbPr Component Video Input Port and Output Port are color-codes RCA female jacks for
each component
3.5 mm jack for the external power supply input
›
➔
›
➔
➔
➔
➔
➔
›
›
›
›
➔
➔
›
›
➔
›
›
›
