• The genuine-accessory car stereo shall have a maximum power output of no more than 25 W.
• Do not connect the speaker output leads from a power amplifier (Optional) to the speaker input
terminals of this unit, for this may cause malfunction or damage.
• Do not connect cables and leads to both RCA cable input jacks and the speaker input terminals
simultaneously, for this may cause malfunction or damage.
• Connect the power control lead to a power supply which can be turned ON/OFF by the ignition
key switch (ACC line).
With this connection, shock noise may be generated when the power of the genuine-accessory
car stereo is switched ON/OFF.
2CAUTION
6
Connection
MONO
POWER AMPLIFIER
L
25Hz
15Hz
INFRASONIC
OFF INPUT
SENSITIVITY(V)
LPF
FREQUENCY(Hz)
GND
R
LINE IN
0.3
0.5
1
2
3 4 5 0.2
150 100
70
50 200
LEFT RIGHT
SPEAKER LEVEL INPUT
- +
MONO
POWER AMPLIFIER
L
25Hz
15Hz
INFRASONIC
OFF INPUT
SENSITIVITY(V)
LPF
FREQUENCY(Hz)
GND
R
LINE IN
0.3
0.5
1
2
3 4 5 0.2
150 100
70
50 200
LEFT RIGHT
SPEAKER LEVEL INPUT
■ RCA cable connection
CENTER UNIT
(Cassette receiver,
CD receiver, etc.)
Power control cable
(Commercially
available part)
RCA cable
(Commercially
available part)
Do not connect cables and
leads to both RCA cable input
jacks and the speaker input
terminals simultaneously, for
this may cause malfunction
or damage.
2CAUTION
RCA cable ground terminal
When using an RCA cable with
a ground lead attached, connect
the ground lead to this terminal.
Do not use this terminal for power source
grounding. This unit will be damaged if the
power source grounding wire is connected
to this terminal.
2CAUTION
Genuine-accessory
car stereo
■ Speaker level input connection
ACC
Battey
Left output (White)
Right output (Red)
Left input Right input
Left input Right input
Left output
Right output
Lead terminal
(Commercially
available parts)
Speaker level input terminals
