TTrriiFFooccaall XX™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: TFX 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

1,150.0 pF @ 20 kHz

• Ls series inductance:

0.543 µH @ 20 kHz

• Rdc dc loop resistance:

0.014 Ω

• Xt total reactance:

0.068 Ω @ 20 kHz

• Frequency response ±0.5 dB High: dc 750 kHz

Med: dc 750 kHz

Low: dc 750 kHz

• Crosstalk Low-Mid 20 100 Hz:

< 98 dB

• Crosstalk Low-Mid 200 Hz 1 kHz:

< 79 dB

• Crosstalk Low-Mid 1 kHz 30 kHz:

< 59 dB

• Crosstalk Mid-High 20 100 Hz:

< 99 dB

• Crosstalk Mid-High 200 Hz 1 kHz: < 80 dB

• Crosstalk Mid-High 1 kHz 30 kHz:

< 60 dB

TTrriiFFooccaall XXLL™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: TFXL 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

1,760.0 pF @ 20 kHz

• Ls series inductance:

0.425 µH @ 20 kHz

• Rdc dc loop resistance:

0.009 Ω

• Xt total reactance:

0.053 Ω @ 20 kHz

• Frequency response ±0.5 dB High: dc 1.0 MHz

Med: dc 1.0 MHz

Low: dc 1.0 MHz

• Crosstalk Low-Mid 20 100 Hz:

< 100 dB

• Crosstalk Low-Mid 200 Hz 1 kHz:

< 81 dB

• Crosstalk Low-Mid 1 kHz 30 kHz:

< 61 dB

• Crosstalk Mid-High 20 100 Hz:

< 102 dB

• Crosstalk Mid-High 200 Hz 1 kHz: < 82 dB

• Crosstalk Mid-High 1 kHz 30 kHz:

< 62 dB

BBiiFFooccaall XX™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: BFX 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

648.0 pF @ 20 kHz

• Ls series inductance:

0.470 µH @ 20 kHz

• Rdc dc loop resistance:

0.064 Ω

• Xt total reactance:

0.168 Ω @ 20 kHz

• Frequency response ±0.5 dB High: dc 750 kHz

Low: dc 750 kHz

• Crosstalk 20 100 Hz:

< 98 dB

• Crosstalk 200 Hz 1 kHz:

< 79 dB

• Crosstalk 1 kHz 30 kHz:

< 59 dB

BBiiFFooccaall XXLL™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: BFXL 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

1,500.0 pF @ 20 kHz

• Ls series inductance:

0.369 µH @ 20 kHz

• Rdc dc loop resistance:

0.024 Ω

• Xt total reactance:

0.046 Ω @ 20 kHz

• Frequency response ±0.5 dB High: dc 1.5 MHz

Low: dc 1.5 MHz

• Crosstalk 20 100 Hz:

< 99 dB

• Crosstalk 200 Hz 1 kHz:

< 80 dB

• Crosstalk 1 kHz 30 kHz:

< 60 dB

“ B i - w i r e ” L o u d s p e a k e r c a b l e s

“ T r i - w i r e ” L o u d s p e a k e r c a b l e s

78

Refer to page 73 for parameters of test.
