L o u d s p e a k e r C a b l e s

44PPRR

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 4PR 2.5m bare wire ends.

• Cp parallel capacitance:

312.0 pF @ 20 kHz

• Ls series inductance:

0.654 µH @ 20 kHz

• Rdc dc loop resistance:

0.041 Ω

• Xt total reactance:

0.0825 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 100 kHz

44VVSS

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 4VS 2.5m 2.5m bare wire ends.

• Cp parallel capacitance:

340.0 pF @ 20 kHz

• Ls series inductance:

0.596 µH @ 20 kHz

• Rdc dc loop resistance:

0.041 Ω

• Xt total reactance:

0.075 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 250 kHz

44TTCC

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 4TC 2.5m bare wire ends.

• Cp parallel capacitance:

362.0 pF @ 20 kHz

• Ls series inductance:

0.715 µH @ 20 kHz

• Rdc dc loop resistance:

0.038 Ω

• Xt total reactance:

0.071 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 500 kHz

88TTCC

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 8TC 2.5m bare wire ends.

• Cp parallel capacitance:

821.0 pF @ 20 kHz

• Ls series inductance:

0.345 µH @ 20 kHz

• Rdc dc loop resistance:

0.018 Ω

• Xt total reactance:

0.044 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 300 kHz

88VVSS

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 8VS 2.5m bare wire ends.

• Cp parallel capacitance:

744.0 pF @ 20 kHz

• Ls series inductance:

0.378 µH @ 20 kHz

• Rdc dc loop resistance::

0.021 Ω

• Xt total reactance:

0.047 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 150 kHz

88PPRR

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: 8PR 2.5m bare wire ends.

• Cp parallel capacitance:

742.0 pF @ 20 kHz

• Ls series inductance:

0.459 µH @ 20 kHz

• Rdc dc loop resistance:

0.021 Ω

• Xt total reactance:

0.057 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 50 kHz

M

Moonnooccllee XX™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: MX 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

789.0 pF @ 20 kHz

• Ls series inductance:

0.946 µH @ 20 kHz

• Rdc dc loop resistance:

0.036 Ω

• Xt total reactance:

0.115 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 750 kHz

M

Moonnooccllee XXLL™™

BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss

DUT: MXL 2.5m terminated with WBT-0660-Cu spades.

• Cp parallel capacitance:

1,199.0 pF @ 20 kHz

• Ls series inductance:

0.874 µH @ 20 kHz

• Rdc dc loop resistance:

0.015 Ω

• Xt total reactance:

0.109 Ω @ 20 kHz

• Frequency response ±0.5 dB dc 1 MHz

Refer to page 73 for parameters of test.
