KKCCAAGG
BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss
DUT: KCAG 1m terminated
with WBT-0147 RCA type connectors.
• Cp parallel capacitance: 51.0 pF @ 20 kHz
• Ls series inductance: 0.71 µH @ 20 kHz
• Rdc dc loop resistance: 0.065 Ω
• Xt total reactance: 0.087 Ω @ 20 kHz
• Frequency response ±0.5 dB dc 10 MHz
KKCCAAGG BBaallaanncceedd
BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss
DUT: KCAG 1m terminated
with XLR type connectors.
• Cp parallel capacitance: 37.10 pF @ 20 kHz
• Ls series inductance: 1.05 µH @ 20 kHz
• Rdc dc loop resistance: 0.119 Ω
• Xt total reactance: 0.132 Ω @ 20 kHz
• Frequency response ±0.5 dB dc 10 MHz
A n a l o g I n t e r c o n n e c t s C o n t .
TTAAKK CCuu
BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss
DUT: TAK 1m terminated
with Ultraplate™ RCA type connectors.
• Cp parallel capacitance: 47.10 pF @ 20 kHz
• Ls series inductance: 1.31 µH @ 20 kHz
• Rdc dc loop resistance: 0.119 Ω
• Ground/Shield: R: 0.065 Ω X: 0.359
• Xt total reactance: 0.162 Ω @ 20 kHz
• Frequency response ±0.5 dB dc 5 MHz
• Crosstalk @ -60dB 92.0 kHz
TTAAKK AAgg
46.50 pF @ 20 kHz
0.89 µH @ 20 kHz
0.089 Ω
R: 0.046 Ω X: 0.257
0.120 Ω @ 20 kHz
dc 10 MHz
360.0 kHz
TTAAKK H H
46.90 pF @ 20 kHz
0.901 µH @ 20 kHz
0.105 Ω
R: 0.061 Ω X: 0.310
0.160 Ω @ 20 kHz
dc 8 MHz
150.0 kHz
P h o n o I n t e r c o n n e c t s
Refer to page 73 for parameters of test.
GGQ Q -- M Miinnii CCuu
BBaassiicc EElleeccttrriiccaall SSppeecciiffiiccaattiioonnss
DUT: GQ - Mini Cu 1m terminated
with 1/8 mini Standard connector
and Kimber Ultraplate™ RCA type connectors.
• Cp parallel capacitance: 61.0 pF @ 20 kHz
• Ls series inductance: 0.84 µH @ 20 kHz
• Rdc dc loop resistance: 0.089 Ω
• Xt total reactance: 0.104 Ω @ 20 kHz
• Frequency response ±0.5 dB dc - 5Mhz
• Crosstalk @ -60dB 92.0 kHz
GGQ Q -- M Miinnii AAgg
54.0 pF @ 20 kHz
0.77 µH @ 20 kHz
0.082 Ω
0.096 Ω @ 20 kHz
dc - 10MHz
360.0 KHz
GGQ Q -- M Miinnii H HBB
58.0 pF @ 20 kHz
0.81 µH @ 20 kHz
0.087 Ω
0.097 Ω @ 20 kHz
dc - 8 MHz
150.0 kHz
with 1/8 mini Gold
and WBT
® -
0147
connectors.
with 1/8 mini Gold
and WBT
® -
0147
connectors.
