Wiring Instructions
SOURCE UNIT
Speaker Outputs
RCA Dummy Plugs
LEFT +
LEFT +
LEFT -
RIGHT -
RIGHT +
AMP 1
AMP 2
High-Level Inputs
LEFT -
RIGHT -
RIGHT +
When using both sets of High L
ev
el inputs
, the supplied RC
A dumm
y plugs must b
e inserted into the AMP 2 inputs in or
der for the fa
der to w
ork
pr
operly
. If the amplifier is being used in an
y other configuration Do Not use the supplied dumm
y plugs!
