Parts list – Keys Fitness Health Trainer HT440EL User Manual
Page 19
Ref #
Part #
Description
Qty
Ref #
Part #
Description
Qty
2
323-00529
FRAME, REAR HT440EL
1
45
302-00497 NYLOCK NUT 1/2"
6
3
323-00530
POST, UPRIGHT 50.8X1.8X750 HT440EL
1
46
302-00723 WASHER 13X26X2
8
4a
323-00531
TUBE, PEDAL LEFT 27X40X1.5X950 HT440EL
1
47
302-00695 HEX HEAD BOLT, 3/8" X 45
4
4b
323-00532
TUBE, PEDAL RIGHT 27X40X1.5X950 HT440EL
1
48
302-00506 WASHER 10X26X2.0(MM)
6
5a
306-00794
PEDAL, LEFT HT440EL
1
49
302-00519 NYLOCK NUT 3/8"
7
5b
306-00795
PEDAL, RIGHT HT440EL
1
50
302-01116 HEX HEAD BOLT, 3/8"*50
2
6a
323-00533
HANDLEBAR, LOWER LEFT HT440EL
1
51
331-00109 BEARING, CHROME 15.8
4
6b
323-00534
HANDLEBAR, LOWER RIGHT HT440EL
1
52
331-00110 BEARING, CHROME 10X15X7
4
7a
323-00535
HANDLEBAR, UPPER LEFT 28.6X2.0X700 HT440
1
53
319-00375 U-JOINT, PEDAL 75X40X3.0 TUBE HT440EL
2
7b
323-00536
HANDLEBAR, UPPER RIGHT 28.6X2.0X700
1
54
323-00537 FRAME, FRONT 60X1.5X500
1
8
304-00025
BELT, 400J6
1
55
306-00797 CAP. PLASTIC HT440EL
2
9
307-00147
CONSOLE, HT440
1
56
302-01465 SPACER, SMALL 12.7X8.5X7
4
10
311-00018
FLYWHEEL (CRANK PULLEY) ALL INNOFIT EXCE
1
57
331-00111 BEARING, ABECS 608ZZ
4
11
331-00056
OUTSIDE BEARING COLLAR
1
58
323-00538 TUBE, RAIL HT440EL-#58
2
12
302-01463
BIG WASHER, HT440EL
1
59
302-01466 SPACEER, BIG 12.7X8.5X9.8
2
13
330-00097
PULLEY AXLE, HT440EL
1
60
306-00799 ROLL, PLASTIC HT440EL
2
14a
311-00095
CRANK, LEFT HT440EL
1
61
306-00800 ROLL, PLASTIC HT440EL
2
14b
311-00096
CRANK, RIGHT HT440EL
1
62
302-01121 CARRIAGE BOLT M6*35 TRI-5.3E
4
15
302-00561
NYLOCK NUT M10
2
63
302-00529 WASHER 6X13X1.0(MM)
4
16
302-01436
C-CLIP, S-17
1
64
302-01467 CAP, NUT M6
4
17
331-00009
BEARING 6003Z, BRONZE
2
65
302-00569 BOLT M8X15
4
18
311-00018
FLYWHEEL (CRANK PULLEY) ALL INNOFIT EXCE
1
66
310-00220 KNOB, TENSION HT440EL
1
19
331-00057
BEARING 6000ZZ
3
67
302-01468 BOLT, TENSION KNOB
1
20
302-01137
FLYWHEEL SPACER 10*13*4MM CM700
1
68
319-00377 CABLE, TENSION 1550 HT440EL
1
21
302-00684
BC NUT 3/8"
1
69
302-01469 BOLT, COMPUTER
2
22
302-01464
ZIP, (#22) HT440EL
2
70
306-00802 SPACER, HT440EL
2
23
302-00709
WASHER 10X19X1.5
4
71
302-01470 BOLT, HT440EL (#71)
2
24
302-00502
NUT 3/8"
1
72
313-00395 WIRE, EXTENSION 900MM
1
25
330-00096
AXLE, FLYWHEEL 9.98X126
1
73
313-00404 WIRE, SENSOR 1350MM
1
26
331-00054
GREASED BEARING 8x13x6
5
74
311-00097 ARM, IDLER HT440EL
1
27
302-00500
NYLOCK NUT M8
8
75
310-00222 GRIP, UPPER FOAM 28.6X3.0X350
2
28
302-00029
SPRING FOR MAGNETIC PLATE CM530/ET530D
1
76
306-00803 CAP, HANDLEBAR 28.6 HT440EL
2
29
319-00078
MAGNETIC PLATE
1
77
305-00218 COVER, PLASTIC LEFT HT440EL
1
30
302-00553
HEX HEAD BOLT M8X60MM
2
78
306-00801 SPACER, IDLER HT440EL
1
31
302-00515
NUT M8
2
79
305-00219 COVER, PLASTIC RIGHT HT440EL
1
32
302-01145
MAGNET, 12.5 * 5
1
80
310-00223 IDLER, HT440EL
1
33
302-01442
NUT CAP, M8 HT440
4
81
302-00588 BOLT M4X16
4
34
302-00490
ARC WASHER 8X19X1.5 (MM)
8
82
302-00705 HEX HEAD BOLT 3/8 * 25
1
35
302-00658
CARRIAGE SCREW M8X70
4
83
302-01132 SCREW M4*44 TRI-5.3E
3
36
302-00699
WASHER, 8X19X1.5, 120E
6
84
306-00210 WHEEL CAP U/R CM520/530/580 DCV5.2
2
37
302-01104
HEX HEAD BOLT M8*40
2
85
306-00798 PLUG, WIRE 12.5 HT440EL
2
38
331-00108
BEARING, CHROME 12.7
8
86
310-00221 FOAM, 31.8X5X60 L HT440EL
2
39
319-00374
U-JOINT, 26*21*2.5
2
87
313-00405 WIRE, PULSE 1 HT440EL
2
40
302-01107
HEX HEAD BOLT M8*55 TRI-5.3E
4
88
313-00406 WIRE, PULSE 2 HT440EL
2
41
306-00796
CAP, LOWER HANDLEBAR HT440EL
2
89
302-01127 SPACER 12.7*37.1 TRI-5.3E
2
42
313-00403
WIRE, PULSE 500MM
2
90
302-01471 SPRING, IDLER HT440EL
1
43
319-00376
TUBE, JOINT 21.3X21.3X2.0X475 HT440EL
2
91
313-00401 HAND PULSE, PE18 HT440
2
44
306-00797
CAP. PLASTIC HT440EL
6
#
302-01462 BOLT PACK, HT440EL
1
HT440EL Parts List Rev A
Parts List
1
