8 9
58
56
48
55
51
54
53
57
5
5a
5. Connect the computer cable (56) that protudes from the
handlebar post into the jack of the computer (57). Attach the
computer to the handlebar post (51) using the screws (58).
5a. Get the tension cable (55) out of the handlebar post’s hole,
and connect it to the tension controller (57) as in steps 1-3:
Step 1: Put the cable end into the spring hook.
Step 2: Pull the knob up into the bracket.
Step 3: Insert the knob into the handlebar post, and secure
with the screw attached. Tension is increased by
turning the knob clockwise.
Steps 1-3
E
Important
This product is designed for use by adults. Precautions must be
taken to prevent children from using or playing with this exercise
bike. This bike must be used on a level surface at all times. Do
not pedal backwards as this will damage the computer, cable and
drive and void the warranty.
