-8-
Filtering address Multicast/Broadcast/Unicast address
MAC address 2K entries
Aging time 300 seconds
Priority levels 2 outgoing priority queues (Ratio: High/Low = 4/1 )
VLAN mode 1. Port-based VLAN 2. 802.1Q VLAN (Tag-based)
VLAN groups 16 groups (Group 0 ~ 15)
Port PVID Full 12-bit VID, per port setting
Port Tag Mode Tag/Untag mode, per port setting
Environment Temperature 0 o C to 40 o C
Relative humidity 10% to 90% non-condensing
Dimensions 144 mm x 100 mm x 26 mm (WxDxH)
5.67 x 3.94 x 1.02 inch
DC IN Power Rating +7.5V min. 1A
DC IN Jack D6.3mm D2.0mm
Operating voltage +6.5 ~ +12.5VDC (Device DC Input)
Power Consumption 7W max. (with power adapter)
1.3 FX Port Optical Specifications
Model Ext. Connector Wavelength Tx optical powerRx sensitivity
-VT
MM *1 ST 1310nm -20 ~ -14dBm -31dBm
-VC MM SC 1310nm -20 ~ -14dBm -31dBm
-VJM MM MT-RJ 1310nm -20 ~ -14dBm -31dBm
-VVM MM VF-45 1310nm -20 ~ -14dBm -31dBm
-VL MM LC 1310nm -19 ~ -14dBm -34dBm
-VSA2 SM *2 SC 1310nm -15 ~ - 8dBm -31dBm
*1 : Multimode fiber
*2 : Single Mode fiber
