Safety Precautions and Tips
It is the owner's responsibility to ensure that all users of this
exercise bike have read the Owner's Manual and are familiar
with warnings and safety precautions.
• This exercise bike has a maximum user capacity of 300
pounds.
• This exercise bike should only be used on a level surface and is
intended for indoor use only. It should not be placed in a
garage, patio or near water. Keys recommends an equipment
mat be placed under the bicycle to the protect the floor or car-
pet and for easier cleaning.
• Wear comfortable, good-quality walking or running shoes
and appropriate clothing. Do not use this exercise bike with
bare feet, sandals, socks or stockings!
• Always examine your exercise bike before using to ensure all
parts are in working order.
• Do not leave children unsupervised near or on the exercise
bicycle.
• Never operate the exercise bicycle where oxygen is being
administered or where aerosol products are being used.
• Never insert any object or body parts into any opening.
• Service to your exercise bike should only be performed by an
authorized service representative, unless authorized and/or
instructed by a Keys technician. Failure to follow these instruc-
tions will void the warranty.
2
ASSEMBLY PARTS
PART #
FRAME 1
SEAT CUSHION 2
BACK CUSHION 3
MONITOR 4
FRONT FOOT TUBE 27
REAR FOOT TUBE 27a
SEAT CARRIAGE 30
SEAT SUPPORT BRACKET 34
PEDALS (LEFT/RIGHT) 35/36
SEAT HANDLEBAR 44
HANDLEBAR 44a
CONSOLE TUBE 49
REAR SUPPORT TUBE 60
CONNECTING COVER (RIGHT/LEFT) 65/66
44
27
35
36
49
2
1
3
60
30
27a
34
4
44a
65/66
