Tri 6.0r recumbent parts list – Keys Fitness 6.0r User Manual
Page 12
20
REF #
PART #
DESCRIPTION
QTY
1
323-00295
FRAME TRI-6.0R DCV6.0R, CM560R
1
2
328-00003
SEAT PAD RECUMBENT, CM535/550/560/750 DCV
1
3
328-00004
BACK PAD RECUMBENT, CM535/550/560/750 DCV
1
4
307-00070
CONSOLE, TRIUMP 6.0
1
5
302-00480
M6 X 1 X 12 LONG ALLEN HEAD SCREW TRI-6.
8
6
311-00068
MAG BRAKE, TRI-6.0R
1
7
331-00016
WASHER CM535/550/560/750 DCV6.0R U/R
1
8
306-00571
SLEEVE, DCV6.0R/TRI-6.0R
2
9
331-00013
BEARING HOUSING CM535/550/560/750 DCV6.0
2
10
331-00006
BEARING CM535/550/560/750 DCV6.0R U/R
2
11
330-00005
CRANK, TRI6.0R DCV6.0R
1
12
311-00020
FLYWHEEL, (CRANK PULLEY) U/R CM535/550/56
1
13
302-00479
M6 X 1 X 10MM MACHINE SCREW TRI-6.0R#13
4
14
304-00006
BELT, 1222J6
1
15
302-00468
M10 X 1MM CAP NUT TRI-6.0R#15
2
16
302-01106
10MM IDX22MM OD WASHER TRI-6.0R
2
17
302-00317
EYEBOLT #41
2
18
302-00399
ADJUSTMENT CHANNEL ALL MACRO BIKES
2
19
319-00176
BELT TENSION BRACKET, TRI-6.0R/DCV6.0R
1
20
302-00407
SPRING 220U
1
21
311-00027
IDLER PULLEY, U/R CM535/550/560/750 DCV6.
1
22
305-00003
BOTTOM COVER LEFT=UP RIGHT=RECUMBENT CM5
1
22a 305-00045
RIGHT REAR COVER DCV6.0R
1
23
305-00005
BOTTOM COVER LEFT=RECUBMENT RIGHT=UPRIGH
1
23a 305-00044
LEFT REAR COVER DCV6.0R
1
24
305-00004
TOP COVER RIGHT=RECUMBENT LEFT=UPRIGHT C
1
25
305-00006
TOP COVER LEFT=RECUMBENT RIGHT =UPRIGHT
1
26
302-00471
M4 X 12MM SHEET METAL SCREW TRI-6.0R#26
6
27
323-00015
FRONT FOOT TUBE #2
1
27a 323-00059
REAR FOOT TUBE #27A
1
28
306-00207
WHEEL U/R CM535/550/560/750 DCV6.0R
2
29
306-00059
FOOT CAP CM560U/R DCV6.0R ET900/920 840E
2
30
323-00073
SEAT CARRIAGE #30 + BRACKET
1
31
302-00476
M5 X 8 X 70 SCREW TRI-6.0R#31
2
32
302-00481
M6 X 1 X 20 SCREW TRI-6.0R#32
1
33
302-00485
M8 X 15 BUTTON HEAD SCREW TRI-6.0R#33
7
34
319-00133
SEAT SUPPORT BRACKET, TRI-6.0R/DCV6.0R
1
35
306-00093
LEFT PEDAL UPRIGHT/RECUMBENT CM535/550/5
1
36
306-00155
RIGHT PEDAL U/R CM535/550/560/750 DCV6.0
1
37
302-00484
M8 X 1.25 X 60MM CARRIAGE BOLT TRI-6.0R#
4
38
302-00478
M6 X 1 NUT TRI-6.0R#38
6
TRI-60.r Parts List Rev B
TRI 6.0r RECUMBENT PARTS LIST
21
TRI 6.0r RECUMBENT PARTS LIST
REF #
PART #
DESCRIPTION
QTY
39
302-00486
M8 X 18.8MM FLAT WASHER TRI-6.0R#39
15
39a 302-01151
SPACER TRI-6.0R
1
40
306-00569
1" BALL PLUG, DCV6.0R/TRI-6.0R
2
40a 313-00134
HAND PULSE, TRI-6.0R
2
41
302-00482
M8 LOCKNUT TRI-6.0R#41
2
42
330-00079
IDLER PULLEY BEARING TRI-6.0R DCV6.0R
1
43
302-00472
M4 X 16MM SHEET METAL SCREW TRI-6.0R#43
14
44
323-00062
REAR HANDLEBAR #44
1
44a 323-00030
HANDLE BAR P44A
1
45
302-00477
M6 X 1 LOCKNUT TRI-6.0R#45
1
46
310-00019
CAM LOCK, CM560R/DCV6.0R/CM835/850U /AB900
1
47
302-00039
MAGNET CM535/550/560/750 DCV6.0R U/R
1
48
313-00133
REED SWITCH, TRI-6.0R
1
49
323-00007
CONSOLE TUBE
1
50
331-00015
NOTCHED BEARING NUT CM535/550/560/750 DC
1
50-1 331-00014
SLOTTED BEARING NUT CM535/550/560/750 DC
1
51
331-00017
CRANK WASHER NOTCHED CM535/550/560/750 D
1
52
302-00475
M5 X 8 HEX NUT TRI-6.0R#52
2
53
302-00488
M8 X 45MM BUTTON HEAD SCREW TRI-6.0R#53
2
53a 302-00487
M8 X 38MM BUTTON HEAD SCREW TRI-6.0R#53A
1
54
302-00483
M8 X 1.25 CAP NUT TRI-6.0R#54
4
55
331-00018
CRANK NUT CM535/550/560/750 DCV6.0R U/R
1
56
315-00029
OWNER'S MANUAL TRI-6.0R
1
57
306-00573
2" SQUARE CAP, DCV6.0R/TRI-6.0R
1
58
307-00075
GEARBOX, TRI 6.0R
1
59
302-00473
M5 X 10 BUTTON HEAD SCREW TRI-6.0R#59
4
60
323-00068
REAR SUPPORT TUBE #60
1
61
319-00156
GEAR BOX PLATE ,TRI-6.0R/DCV6.0R
1
62
302-00469
M3.5 X 15MM SHEET METAL SCREW TRI-6.0R#6
3
63
319-00134
HANDLEBAR QUICK ADJUST, TRI-6.0R/DCV6.0R
1
64
306-00572
SLEEVE, DCV6.0R/TRI-6.0R
2
65
305-00087
CONNECTING COVER RIGHT TRI-6.0R
1
66
305-00086
CONNECTING COVER LEFT TRI-6.0R
1
67
302-00317
EYEBOLT #41
2
68
302-00399
ADJUSTMENT CHANNEL ALL MACRO BIKES
2
69
302-00368
6MM HEX NUT MACRO
2
70
302-00474
M5 X 50MM SHEET METAL SCREW TRI-6.0R#70
2
71
313-00131
EXTENSION WIRE, TRI-6.0R
1
72
302-00470
M3X 8MM SHEET METAL SCREW TRI-6.0R#72
2
73
313-00132
SENSOR, TRI-6.0R
1
N/A 302-00046
BOLT PACK CM535/550/560/750 RECUMBENT
1
TRI-60.r Parts List Rev B
