17
PARTS LIST
MODEL NO: IN2636SQB-1
NO. DESCRIPTION MODEL/SIZE PART NO.
1 Exhaust Plate XP26618 / GP056010
2 Hood Casing GP054710
3 Wiring Box XP14441
4 ISC IN2636-100-01
5 Processor Board IN2636-101-01
6 Capacitor XP22420
7 Support Panel GP055807
8 Processor Board Box GP055607 / GP055707
9 Indicator Sensor IN2636-102-01
10 Control Unit IN2636-103-01
11 Blower System MT023
12 Bottom Casing GP054806
13 Baffle Filter Support GP055006 / Q0192 / GP055106
14 Oil Tunnel IN2636-104-01
15 Stainless Steel Spacer GP055206
16 Baffle Filter Q0193
17 Control Unit Support GP055507
18 Light Socket XP26624
19 Light Panel GP054906
20 Halogen Light bulb XP27401
Optional Liner (Sold Separately)
21 Rear Liner Section INL36252A IN2636-12-01
INL42252A IN2636-13-01
INL48252A IN2636-14-01
22 Front Liner Section INL36252A IN2636-1202
INL42252A IN2636-13-02
INL48252A IN2636-14-01
