9
GROOVE 1200
Specifications
The GROOVE 1200 was designed to mount into a standard 2-space rack. When mounting, use 4
screws to secure the amplifier to the rack. When using only one amplifier, use the bottom 2 spaces in the rack.
However, if more than one amplifier is used, leave one space open between the amplifiers to ensure proper
ventilation (shown below).
Rack Mounting Instructions
Input Impedance
Output Power
450 Watts
8 Ohms @ 5% THD
750 Watts
4 Ohms @ 5% THD
1200 Watts
2 Ohms @ 5% THD
Hum & Noise
-60db
Residual Noise, all level controls 0% (minimum)
27db
Preamp output
15db
Preamp output, Active
25db
Tuner output
27db
Direct output
32db
Power amp gain
Amplifier Type
Class B
Descrete device Class B amplifier
USA/Canada
120VAC/60Hz, 1500W nominal
Europe
230VAC/50Hz, 1500W nominal
UK
230VAC/50Hz, 1500W nominal
Australia
240VAC/50Hz, 1500W nominal
Japan
100VAC/50-60Hz, 1500W nominal
mm/kg
89 (Height) x 483 (Width) x 390 (Depth), 14 kg
Inches/Pounds
3.5 (Height) x 19 (Width) x 15.5 (Depth), 31 lbs
Actual response is tailored to speakers for accurate acoustical
response using a bass guitar as input.
Dimensions
Power Requirements
Footswitch
System Gain
All measurements taken with 1 KHz
input signal, Tone controls flat, Gain and
Volume Maximum. Measured at effects
send output jacks on rear unless noted.
200K Ohm
Use any standard tip-ring-sleeve cable
Any non-momentary two-button foot switch can be used.
Frequency Response
20HZ-20kHz
