CONNECTING ANALOG CABLE, CABLE BOX, VCR, AND AN ANTENNA TO
THE DTV
VIDEO2 COMPOSITE (ANALOG) JACKS: Connection Option 1
VCR
1 Connect Analog Cable Box “Antenna Out” to the
VCR “Antenna In.”
2 Connect the VCR AV out jacks to VIDEO1 Yellow,
White, and Red jacks.
3 3 OPTIONAL FOR A SUPER VHS VCR
Connect VCR to the DTV S-Video In Jack. Discon-
nect the VIDEO2 yellow connector
4 Tune VCR to channel 3 or 4 to match your Cable
Box.
5 Press INPUT to select Video 2 to watch Analog
Cable channels OR to TV channels to watch
Antenna channels.
6 Select Cable channels with the cable box remote
control. Select Antenna channels with the DTV
remote control.
IMPORTANT FACTS: Composite jacks offer only 480i
(SDTV) resolution.
“No Signal” will appear randomly
on the screen when no signal is
detected at the video jack. ● Check Audio / Video connections.
● Check external equipment
connections.
● Check external equipment
setting.
● Press the INPUT key.
● Switch on external equipment.
● Set external equipment output
connections to match input
connections.
SYMPTOM CHECK THESE CONDITIONS TRY THESE SOLUTIONS
If you continue to experience problems, please call toll free
1-800-877-5032. We can Help!
CABLE BOX
❷
OPERATING TIP:
Refer to the owner’s manuals and user’s
guides that came with your external equip-
ment for connection options.
③
❶
CABLE SYSTEM
(Service provider)
HELPFUL HINTS (PROBLEMS/SOLUTIONS)
DTV VIDEO2
REMOTE CONTROL
❺
INPUT
YELLOW,
WHITE, & RED
JACKS
VCR
S-VIDEO JACK
(Optional)
