Model W1802 2 QT. Professional Spray Gun
-17-
W1802 PARTS LIST
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 X1802101 POT BOTTOM 126 X1802126 FLUID CONTROL SCREW
102 X1802102 CUP 127 X1802127 FLUID ADJ. SCREW
103 X1802103 FLUID TUBE 128 X1802128 PATTERN ADJ. SCREW
104 X1802104 COVER 129 X1802129 O-RING 2.5 X 2.1
105 X1802105 RUBBER WASHER 130 X1802130 PATTERN ADJ. KNOB
106 X1802106 LATEX JAM 131 X1802131 SNAP RETAINER
107 X1802107 COMPRESSION SPRING 132 X1802132 PATTERN ADJ. NEEDLE
108 X1802108 SPRING RELIEF VALVE 133 X1802133 TRIGGER PIN
109 X1802109 PAINT INLET PLUG 134 X1802134 TRIGGER
110 X1802110 CENTERPOST 135 X1802135 SNAP RETAINER
111 X1802111 FLUID OUTLET 136 X1802136 CONNECT SCREW
112 X1802112 SPECIAL NUT 137 X1802137 SPECIAL WASHER
113 X1802113 HANDLE 138 X1802138 HEAD
114 X1802114 REGULATOR ASSEMBLY 139 X1802139 FLUID NOZZLE
115 XPS17M PHLP HD SCR M4-.7 X 6 140 X1802140 AIR CAP
116 X1802116 CHECK VALVE 141 X1802141 DIRECTION SCREW
117 X1802117 COMPRESSION SPRING 142 X1802142 SWITCH SPRING
118 X1802118 SPECIAL WASHER 143 X1802143 SWITCH PIPE
119 X1802119 COMBO HOSE 144 X1802144 SEALING WASHER
120 X1802120 AIR INLET PLUG 145 X1802145 SWITCH SEAT
121 X1802121 BLOCK 146 X1802146 SPECIAL WASHER
122 X1802122 GUN BODY 147 X1802147 SPECIAL NUT
123 X1802123 DIRECTION PIPE 148 X1802148 BRUSH
124 X1802124 FLUID ADJ. NEEDLE 149 X1802149 SERVICE WRENCH
125 X1802125 SPECIAL WASHER
