Mounting
Steps 1 and 2
6
24/96 AD-DA Converter 2053
Step 1:
Please put the converter module as illust-
rated on the unit top and remove the screws of the
cover from the back of the upgrade unit.
Step 2:
Please remove the mounting of the wiring on
the back of the cover (eventually cut off the silicon).
Socket
Socket
Connector
