Example 1: Processing a sampler's signal
Connect the output of the sampler via AES/EBU or
S/P-DIF interface with the input of the converter. The
adjustment described in the section above now
allows to process the sampler's signal. If the processed
signal is to be returned digitally converted to the
sampler, the A/D converter has to be synchronized to
the D/A converter (= external synchronization; the
D/A converter is the source clock for the A/D
converter). In this case, please set the AD MODE switch
on the converter module to position "5" (24 Bit) or "D"
(16 Bit).
Example 2: Recording on a DAT recorder
If the processed signal is to be recorded on a DAT
recorder, the best Bit-format of the DAT-recorder must
be chosen on the AD MODE switch (16 or 24 Bit), while
the internal synchronization should be adapted to the
desired sample rate. For 16 Bit operation choose one
of the switch positions B, A, 9 or 8, for 24 Bit 0, 1, 2, or 3.
Unless a House-Clock controls all digital units: in this
case please set the AD MODE switch to position C for
16 Bit or 4 for 24Bit (compare chapter "Operation,
internal and external synchronization", page 11).
