Issue 7 72
Technical data
Item Minimum Maximum
Overall length with legrest 1100 mm
Overall width 640 mm
Total mass (depending on options fitted) 110 kg
Mass of heaviest part 80 kg
Load 127 kg
(with seat riser option) (100 kg)
Seat riser option adjustment approx. 30 cm
(Max. speed 25% when seat is in raised
position)
Obstacle climbing (without kerb climber) 52 mm
(with kerb climber) 112 mm
Forward speed 6 km/h (10 km/h optional)
Braking distance from maximum speed 870 mm
Seat plane angle 8°
Effective seat depth with standard seat 410 mm 510 mm
(with seat riser option via backrest and (460 mm) (510 mm)
additional depth adjustment via legrests)
Effective seat width 450 mm 500 mm
(with seat riser option) (360 mm)
Seat surface height at front edge 425 mm 510 mm
Backrest angle 0° 40°
Backrest height 520 mm
Footrest to seat distance 340 mm 410 mm
Leg to seat surface angle 240°
Armrest to seat distance 180 mm 245 mm
Front location of armrest structure 180 mm 200 mm
Turning circle 1300 mm
