19 Issue 7
Fig. 12
Armrest height adjustment Allen screw
Adjusting the armrest width
To adjust the width, loosen the two bolts
as shown in Fig. 12, move the armrest
assembly to the desired position and
tighten the bolts firmly prior to use.
Armrests
Adjusting the armrest height
To adjust the height, loosen the adjusting
Allen screw, move the armrest to the
desired position and tighten the Allen
screw (Fig. 13).
Fig. 13
Adjustment bolts
