F.6 Connector Details
Headphones
Location: Front Panel
Conn’ Type: Stereo 1/4" Jack Socket
Pin Description
Tip Left
Ring
Sleeve 0V
PL2
Location: Internal
Conn’ Type: 16-pin IDC Plug
Pin Description
n/a For Future Expansion
Ins Rtn, Ext, Mon, Alt Mon
Location: Rear Panel
Conn’ Type: 25-pin ‘D’ Type Female
Pin Description
1 Alt Monitor Out Right (+ve)
14 Alt Monitor Out Right (–ve)
2 0V
15 Alt Monitor Out Left (+ve)
3 Alt Monitor Out Left (–ve)
16 0V
4 Main Monitor Out Right (+ve)
17 Main Monitor Out Right (–ve)
5 0V
18 Main Monitor Out Left (+ve)
6 Main Monitor Out Left (–ve)
19 0V
7 External Input Right (+ve)
20 External Input Right (–ve)
8 0V
21 External Input Left (+ve)
9 External Input Left (–ve)
22 0V
10 Mix Insert Return Right (+ve)
23 Mix Insert Return Right (–ve)
11 0V
24 Mix Insert Return Left (+ve)
12 Mix Insert Return Left (–ve)
25 0V
13 n/c
Ins Snd, Mix, Rec, Fol Mon
Location: Rear Panel
Conn’ Type: 25-pin ‘D’ Type Female
Pin Description
1 Follow Monitor Right (+ve)
14 Follow Monitor Right (–ve)
2 0V
15 Follow Monitor Left (+ve)
3 Follow Monitor Left (–ve)
16 0V
4 Record Output Right (+ve)
17 Record Output Right (–ve)
5 0V
18 Record Output Left (+ve)
6 Record Output Left (–ve)
19 0V
7 Mix Output Right (+ve)
20 Mix Output Right (–ve)
8 0V
21 Mix Output Left (+ve)
9 Mix Output Left (–ve)
22 0V
10 Mix Insert Send Right (+ve)
23 Mix Insert Send Right (–ve)
11 0V
24 Mix Insert Send Left (+ve)
12 Mix Insert Send Left (–ve)
25 0V
13 n/c
