X-Rack Installation and Operation
5.3 Physical Specification *
Depth:
180mm / 7.2 inches
excluding front panel knob(s) and connectors
255mm / 10.2 inches
including connectors, excluding front panel knob(s)
Height:
178mm / 7 inches (4 RU)
excluding feet
Width:
440mm / 17.4 inches
excluding rack ears
483mm / 19 inches
including rack ears
Weight:
2.8kg / 6.2 pounds
without modules fitted
3.5kg / 7.7 pounds
with blank panels fitted
5.0kg / 11 pounds
with modules fitted
Power:
50 Watts / 60VA
with 8 modules fitted
Boxed size:
540mm x 300mm x 270mm / 21.25" x 12" x 10.63"
Boxed weight:
4.3kg / 9.5 pounds
without modules fitted
5.0kg / 11 pounds
with blank panels fitted
6.5kg / 14.3 pounds
with modules fitted
* All values are approximate
5.4 Environmental Specification
Temperature
Operating:
5 to 30 Deg. C
Non-operating:
–20 to 50 Deg. C
Max. gradient:
15 Deg. C/Hour
Relative Humidity
Operating:
20 to 80 %
Non-operating:
5 to 90 %
Max. wet bulb:
29 Deg. C (non-condensing)
Vibration
Operating:
< 0.2 G (3 - 100Hz)
Non-operating, power off:
< 0.4 G (3 - 100Hz)
Shock
Operating:
< 2 G (10mSec. Max.)
Non-operating:
< 10 G (10mSec. Max.)
Altitude
Operating:
0 to 3000m (above sea level)
Non-operating:
0 to 12000m
