Page 18
X-Rack Owner’s Manual
X-Rack Connector Details (cont.)
Mix Bus Link
Location: Rear Panel
Conn’ Type: 25-pin ‘D’ Type Female
Pin Description
1 Chassis
14 AFL/Solo Bus Left (–ve)
2 AFL/Solo Bus Left (+ve)
15 Chassis
3 AFL/Solo Bus Right (–ve)
16 AFL/Solo Bus Right (+ve)
4 Chassis
17 Mix Bus Left (–ve)
5 Mix Bus Left (+ve)
18 Chassis
6 Mix Bus Right (–ve)
19 Mix Bus Right (+ve)
7 Chassis
20 Record Bus Left (–ve)
8 Record Bus Left (+ve)
21 Chassis
9 Record Bus Right (–ve)
22 Record Bus Right (+ve)
10 Chassis
23 AFL/Solo Enable
11 n/c
24 n/c
12 n/c
25 n/c
13 n/c
