15
Setting digital out
If the optical DIGITAL OUT socket is connected to the amplifier, you must
set as follows:
1.
Press the SETUP button in the stop mode. The setup screen appears.
2. Press the a button to select “Digital Out”, then press the ENT button.
“Digital Out” screen appears.
3. Press the 5 or 4 button to select the item (highlighted), then press the
ENT button. The submenu appears.
Example: To set “Dolby Digital”
“MPEG” setting is applied also to VCD.
4. Press the 5 or 4 button to select the submenu (highlighted).
Example: To select “Dolby Digital: BitStream”
5. Press the ENT button. (In this example, “Dolby Digital: BitStream”
remains.)
6. Repeat steps 3 - 5 for other items.
7. Press the 4 button to skip back to the setup screen (or press the
SETUP button).
96kHz LPCM (96kHz Liner Pulse Code Modulation):
If your amplifier is available for 96kHz sampling, select “96kHz LPCM”. If
not, select “48kHz LPCM”.
Note:
-
When “48kHz LPCM” is set, there are 48kHz LPCM audio signals from
the AUDIO OUT and AV EURO CONNECTOR sockets, not 96kHz
LPCM audio signals.
- When playing back the DVD disc which recorded with 96kHz LPCM,
there is no digital output.
- But playing back the DVD disc with no copyright protection, the sound
is original recorded sound.
Dolby Digital:
If your amplifier has Dolby Digital decoder, select “BitStream”. If not, select
“LPCM”.
DTS:
If your amplifier has DTS decoder, select “On”. If not, select “Off”.
MPEG (Moving Picture Expert Group):
If your amplifier has MPEG-2 decoder, select “BitStream”. If not, select
“LPCM”.
Setting parental
1. Press the SETUP button in the stop mode. The setup screen appears.
2. Press the a button to select “Parental”, then press the ENT button.
“Parental” screen appears.
3. Press the 5 button to skip “Password: ----” and select “Level”.
4. Press the ENT button repeatedly to select the parental lock level
(“Level: Off, 1 ~ 8”).
Example: To set “Level 1”
5. Press the 4 button to return to “Password: ----”.
6. Enter a number in 4 digits.
Note:
If you make a mistake, press the CLEAR button.
7. Press the ENT button. The password is now set.
Note:
If you do not set it, Parental control does not work, and it returns to the
initial settings.
8. Press the SETUP button. The setup screen disappears.
Parental control
MPAA (Motion Picture Association of America) guideline is a rating
system that provides advanced cautionary information to parents about
the content of movie programmes.
The parental lock level is equivalent to the following MPAA rating system.
Level 7: NC-17 (No one 17 and under admitted)
Level 6: R (Restricted)
Level 4: PG-13 (Parents strongly cautioned)
Level 3: PG (Parental guidance suggested)
Level 1: G (General audiences)
Some DVD discs contain a restriction level which enables parents to
prevent playback of discs by children. This unit is equipped with a
password designed to prevent children changing the level.
You cannot play DVD discs rated higher than the level you selected unless
you cancel the parental lock function.
For example, when you select level “5”, the unit will not play discs with
ratings of “6”, “7” or “8”. The information will appear on the TV screen.
If you forget the password…
Enter “788444” even if 4 digits “----” appears, then press the ENT button
to clear the current password. Enter a new password and set the parental
lock level again.
Note:
DVD discs may or may not respond to the parental lock settings. Make
sure this function works with your DVD discs.
Language Display Digital Out Parental
96kHz LPCM
Dolby Digital
DTS
MPEG 48 kHz LPCM
LPCM
Off
LPCM
96kHz LPCM
Dolby Digital
DTS
MPEG 48 kHz LPCM
LPCM
Off
LPCM
LPCM
BitStream
96kHz LPCM
Dolby Digital
DTS
MPEG 48 kHz LPCM
LPCM
Off
LPCM
LPCM
BitStream
Language Display Digital Out Parental
Language Display Digital Out Parental
Password
Level ----
Off
Password
Level
1
****
Password
Level
1
----
Password
Level ----
Off
Password
Level ----
1
Language Display Digital Out Parental
