5
On the masking tape mark the polarity of the speaker wires (+ & -), as well as left or
right, and front or rear.
Repeat this procedure for all of the speakers.
Mark the power, ground, and any other wires also.
Installation method A
After inserting the holder into the dashboard, select
the appropriate tab and bend them inwards to
secure the holder in place.
Insert fingers into the groove in the front of frame
and remove it.
Insert the levers supplied with the unit to the
grooves at both sides. The unit can be installed or
removed from the dashboard.
Installation way (method 2)
Installation using the screw holes at both sides of the unit.
1. Select a position where the screw holes of the main unit are fitted for aligned, and
tighten the screws at 2 positions at each side.
