GC-STC BLOWER HOUSING ASSEMBLY
Ref. Part
No. Number Description
-Note-
Some of the hardware is common hardware and you may purchase it locally. Be sure that all bolts
purchased locally are a grade 5.
1 04067-07 Pin, Ring 2-1/4" Long
2 481547 Lanyard, Deck Height Pin
3 04019-02 Nut, Serr. Flange 1/4-20
4 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4"
5 04001-01 Bolt, Hex Head 1/4-20 x 3/4"
6 423298 Belt Cover, Rear
7 481428 Grip, Blower Lever
8 482300 Cap, Square
9 04024-02 Nut, Push On 3/8 Thread
10 04021-05 Lock Nut, 3/8-16
11 04041-07 Flatwasher, 3/8-.391 x .938 x .105
12 43277 Spacer
13 482299 Pulley, Idler 4" Dia.
14 04021-09 Nut, Elastic Stop 3/8-16
15 04030-04 Lockwasher, 3/8-16
16 423296 Plate, Catch Mounting
17 04003-05 Bolt, Carr. 3/8-16 x 1-1/2"
18 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
19 04001-62 Bolt, Hex Head 3/8-16 x 3-1/4"
20 04001-45 Bolt, Hex Head 3/8-16 x 2"
21 461519 Idler Arm Weldment
22 482278 Belt, GC-STC
23 482079 Pulley, 4" O.D.
24 04043-04 Washer, 3/8 Hardened
25 43575 Pivot, Idler
26 481039 Decal, Belt Cover
27 04019-04 Nut, Serr. Flange 3/8-16
28 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2 Gr. 8
29 482293 Decal, Danger
30 461342 Blower Housing Weldment, includes item #29
31 04003-12 Bolt, Carr. 5/16-18 x 3/4" Gr. 5
32 04063-06 Key, 1/4 x 1/4 x 1-1/2"
33 45491 Fan Weldment
34 48915 Bearing with Locking Collar
35 04021-10 Nut, Elastic Stop 5/16-18
36 04040-04 Flatwasher, 5/16-.344 x .688 x .065
37 421319 Cover, Blower Housing
38 48136-01 Clamp, 6-1/2" Max Dia.
39 48135-10 Hose, 6" Dia.
40 482298 Pulley, 4-3/4" O.D. - 1" Bore
41 04012-04 Set Screw, 5/16-18 x 3/8"
42 461343 Frame Weldment, Blower Mount
43 481522 Spring, Main Drive
44 43212 Spacer
45 04019-03 Nut, Serr. Flange 5/16-18
