ENGLISH
23
LISTENING TO A PROGRAM SOURCE
Operations
Before operation
Select the desired input source.
3
• Enter the standby mode.
• The STANDBY button lights up in amber.
This means that the unit is not
disconnected from the AC mains and a
small amount of current is retained to
support the operation readiness.
• To switch the power off, push the POWER switch again.
• Then power is cut off and the STANDBY button goes
off.
• Each time the STANDBY button on the front panel
is pressed, the unit is turned on to enter the
operating mode (the STANDBY button lights up in
blue) or off to enter the standby mode(the
STANDBY button lights up in amber).
• On the remote control, press the POWER ON button
to enter the operating mode or press the STANDBY
button to enter the standby mode.
• In the standby mode if the INPUT SELECTOR
button is pressed, the unit is turned on automatically
and the desired input is selected.
• Then the SPEAKER indicator ( ) lights up and the
sound can be heard from the speakers.
• When using the headphones for private listening,
press this button again to switch the speakers off,
then the SPEAKER indicator (
) goes off(speaker
off mode).
In the standby mode, turn the power on.
1
Switch the speakers on.
2
or
STANDBY POWER ON
AUD1
TUNER VID1
CD VID2
T.MON VID3
AUX VID4
PHONO VID5
PAGE1
STANDBY POWER ON
MAIN PAGE FAV
MUTE
CH. SET VOL
RETURN
DISP
MI
OSD/MENU
1 STEREO
CH/ ADJUST
2 3
4 5 6
7 8 9
0 ENT
M2 M3
DSP DECODE DSP
RNC-510
or
POWER ON
POWER ON STANDBY
Notes : • Before operating this unit with the supplied remote control, refer to “ Universal Remote Controls” on page 16 for details
about operation.
• Before operating this unit, first set this unit as desired for optimum performance, doing the OSD menu setting procedures.
(For details, refer to “OSD Menu Settings” on page 42.)
• Each time the “AUDIO” button is pressed, the input
source changes as follows:
PHONO TUNER CD AUX
(frequency display)
• Each time the “VIDEO” button is pressed, the input
source changes as follows:
VIDEO 1 VIDEO 2 ------- VIDEO 6
• When the TAPE MONITOR button is set to on so that
“TAPE MON” lights up, other inputs can not be heard
from the speakers.
To listen to an input source except TAPE MONITOR, be sure
to set the TAPE MONITOR button to off.
TAPE MONITOR function
You can connect either a tape deck or a graphic equalizer to the
unit’s TAPE MONITOR jacks.
Only when you listen to the component connected to these
jacks, set the TAPE MONITOR button to on.
If you connect a 3-head tape deck, you can listen to the sound
being recorded during recording, not the source sound.
For further details, refer to the operating instructions of the
component connected.
When selecting the 8 CH DIRECT as desired
• Depending on the surround back speaker setting, “8(,7 or 6)
CH DIRECT” is displayed and the 8(/7/6) separate analog
signals from the component connected to this input pass
through the tone, volume and bass management(if selected)
circuits only and can be heard from your speakers.(In case
that the TAPE MONITOR button is set to on, the TAPE
MONITOR button is automatically set to off.)
• Press the 8 CH DIRECT button or select the desired input
source to cancel the 8 CH direct function.
• These analog signals can be heard only. They cannot be
recorded.
STANDBY POWER ON
AUD1
VID6 7.1IN
DTS PL2MV
DOLBY PL2MS
PCM NEO6C
MPEG NEO6M
PAGE2
or
8CH DIRECT
