14
Location
Introduction
WARNING
Important:Observe all governing codes and ordinances.
Check the location where air conditioner will be installed. Proper installation is your responsibility. Make sure you
have everything necessary for correct installation.
The location should provide:
Grounded electrical outlet within four feet(122cm)of the window. Do not use an extension cord.
Free movement of air to rooms to be cooled.
A large enough opening for the air conditioner. Installation parts are supplied for double-hung windows up to 38"
(96.5cm) wide.
Adequate wal support for the weight of the air conditioner. (Air conditioner weighs between 56 to 80 lbs)
Do not install the air conditioner in an area where the front panel will be exposed to heat sources that will raise the
panel suface temperature above 120 0 F
Window opening
measurements
Excessive Weight Hazard
Use two or more people to move and install air conditioner.
Failure to do so can result in back or other injury.
1 6"
(40.6cm)
26"to38"
(66cm to 96.5 cm)
25"to38"
(63.5cm to 96.
5cm)
8000-12,000
BTUs
5000-6000
BTUs
Air Conditioner Size
1 6"
(40.6cm)
A B
