10
Check that air conditioner cabinet is tilted to the outside so that water will run to the
outside.
Place level (B) on the top,right side of air conditioner cabinet, There should be a tilt
to the outside of about 1/2bubble on the carpenter's level. (C) Place level on left
sode of air conditioner and check that cabinet is tilted properly, If cabinet is not
properly positioned. reposition or shim cabinet to provide the proper tilt.
Pull left curtain (D) out until it fits firmly into the window channel (E). Repeat with right
curtain.
Insert one of the round-head screws (F) through left curtain and into the window channel
or through alternate hole (G) at the top of the curtain and into the window channel to
fasten the curtain to the window. Repeat for right curtain.
