Installation Guide
4
SCM installation checklist
The following table describes the possible installation scenarios for the SCM, the appropriate tasks to
complete for the scenarios, and the order to complete the tasks:
SCM is being..... Configuration Tasks to complete and order to complete them
Installed in a RadiSys shelf Standard configuration. 1. Install the SCM in the shelf on page 5
2. Connect to the SCM on page 6
3. Verify switch operation on page 7
4. Verify shelf management operation on page 10
____
____
____
____
Installed in a non-RadiSys
shelf Post-installation configuration required:
After installation of the SCM in the
non-RadiSys shelf, you must disable the
SCM’s on-board Shelf Manager. 1. Install the SCM in the shelf on page 5
2. Disable the Shelf Manager on the SCM on page 10
3. Verify switch operation on page 7
____
____
____
Removed from a non-RadiSys
shelf and reinstalled in a
RadiSys shelf Pre-removal configuration required:
Before you remove the SCM from the
non-RadiSys shelf, you must enable the
SCM’s on-board Shelf Manager. 1. Enable the Shelf Manager on the SCM on page 12
2. Remove the SCM from the non-RadiSys shelf. For
SCM removal instructions, see the ATCA-2210 Switch
and Control Reference.
3. Install the SCM in the shelf on page 5
4. Connect to the SCM on page 6
5. Verify switch operation on page 7
6. Verify shelf management operation on page 10
____
____
____
____
____
____
