PROMENTUM™
SWITCH AND CONTROL MODULE
INSTALLATION GUIDE
ATCA-2210
This document describes how to install and to set up the
Promentum™ ATCA-2210 switch and control module
(SCM).
Obey ESD precautions
W
ARNING
!
Obey the electrostatic discharge (ESD)
procedures described
the product.
Electrostatic discharge can cause permanent damage to
static-sensitive components in this product. Important ESD
procedures include:
Keep the product in its ESD shielding bag until a step
tells you to remove it.
Put on a grounded wrist strap before you move near or
touch the product.
Install the product only in a grounded work area.
Prepare for installation
The installation of the SCM requires the following:
An AdvancedTCA® (ATCA®) shelf, such as a RadiSys
ATCA-6000, ATCA-6006, ATCA-6014, or ATCA-6016
shelf
A 9-pin D-shell to RJ-45 serial port cable (shipped
with the SCM)
A standard crossover Ethernet cable
Adequate ventilation for the shelf
Install SFPs or XFPs on the SCM
The SCM comes with sockets for small form-factor
pluggable (SFP) and 10 Gigabit small form-factor
pluggable (XFP) transceiver modules. If SFPs and XFPs
are installed, they can provide external connections to the
Ethernet interfaces. The sockets are accessed from the
faceplate of the SCM.
007-02524-0004 • September 2008
Copyright © 2006-2008 by RadiSys Corporation. All rights reserved.
RadiSys is a registered trademark and Promentum is a trademark of RadiSys Corporation. Linux is a registered trademark of Linus Torvalds. AdvancedTCA and ATCA are
registered trademarks of PCI Industrial Computer Manufacturers Group. Procomm Plus and Symantec are registered trademarks of Symantec Corporation. All other
trademarks, registered trademarks, service marks, and trade names are the property of their respective owners.
Document Outline
- Obey ESD precautions
- Prepare for installation
- Install SFPs or XFPs on the SCM
- SCM installation checklist
- Install the SCM in the shelf
- Connect to the SCM
- Verify switch operation
- Verify shelf management operation
- Disable the Shelf Manager on the SCM
- Enable the Shelf Manager on the SCM
- Rear I/O connectivity
- COM Express module setup
- Where to go from here
- Where to get more product information
