Speco Technologies LPRB922 - Manual (Page 6)

2.2 Specifications
Image system
Signal system NTSC
Image Sensor 1/3" SONY CCD
Effective pixels 768 (H) x 494 (V)
Electric
Scanning system
2:1 Interlace V: 59.94Hz
H: 15.734KHz
Sync system Internal
Horizontal resolution 600 TV lines
Built-in lens
f=9mm ~ 22mm, F1.4 DC iris varifocal IR-corrected lens
External adjustments (zoom and focus)
View angle
Horizontal: 32.1° (wide) ~ 13.1° (tele)
Vertical: 23.3° (wide) ~ 9.8° (tele)
Gamma correction 0.45
Minimum illumination 0 Lux (IR LEDs ON)
S/N ratio More than 50dB (AGC off)
BLC Auto (Center Weighting)
Video output 1Vpp composite output, 75 Ohm
IR LEDs 36 Super power LEDs
IR wavelength 850nm
IR distance 50 ft.
Capture range 10~27 ft.
Capture speed 55 MPH
LED life More than 10,000 hours (122 ℉)
Power supply
Power requirement Dual voltage: 12V DC / 24V AC
Power consumption 10W (max.)
Environment
Operating Temp. -14 ℉ ~122 ℉
Mechanism
Dimensions
3.26" H x 8.09" W
Weight 1.35 lbs.
Construction
Sunshield; Cable management bracket
Compact die-cast aluminum; Tempered Glass
Protection class IP66 weatherproof rating; Vandal-resistant
Speco Technologies 200 New Highway, Amityville, NY 11701 1-800-645-5516 www.specotech.com
Speco Technologies is constantly developing product improvements
We reserve the right to modify product design and specifications without notice and without incurring any obligation
Rev. 3/15/10
