Spalding 21196804 - Manual (Page 14)

14
P/N 21196804 10/04
12
6
12
13
13
11
9
10
10
12.
6
8
14
14
17
15
13.
Attach spacers (12, 13) to pole mount bracket (6) with bolts (9), washers (10), and
nuts (11) as shown.
Assemble lanyard (17) to locking pin (16) as shown. Attach covers (14) onto
pole mount bracket (6) with carriage bolt (15) and nut (8) as shown.
DO NOT OVERTIGHTEN
16
Loop end of pin lanyard (17)
over carriage bolt (15) as it
passes through the pole
mount bracket (6) during this
assembly.
IMPORTANT!:
15
17
6
14
8
14
IMPORTANT!:
Tighten just until
washers (10) stop
moving.
