CPD-E200E

2-4. PICTURE TUBE REMOVAL

3

Two screws
(+BVTP 4 x 16)

5

Base assembly

4

Two screws
(+BVTT 4 x 8)

Connector (7 pin)

6

Four screws
(Tapping screw 5)

11

Deflection yoke

10

Neck assembly

8

Degaussing coil assembly

2

A board

9

Two extention springs

1

Anode cap

12

Two degaussing coil holders

13

Two degaussing coil holders

7

Picture tube

Bezel assembly

Cushion

8 pin

2 pin

CN2

CN601

GND

CN303

2-3
