Sony AEP MODEL CPD-E200E - Manual

CHASSIS
SERVICE MANUAL
SPECIFICATIONS
MICROFILM
D99C
AEP Model
Chassis No. SCC-L31C-A
TRINITRON
®
COLOR COMPUTER DISPLAY
CPD-E200E
CRT 0.24 mm aperture grille pitch (center)
17 inches measured diagonally
90-degree deflection
FD Trinitron
Viewable image size Approx. 327 × 243 mm (w/h)
(12 7 / 8 × 9 5 / 8 inches)
16.0" viewing image
Resolution
Maximum Horizontal: 1600 dots
Vertical: 1200 lines
Recommended Horizontal: 1024 dots
Vertical: 768 lines
Standard image area Approx. 312 × 234 mm (w/h)
(12 3 / 8
× 9 1 / 4 inches)
Deflection frequency* Horizontal: 30 to 85 kHz
Vertical: 48 to 120 Hz
AC input voltage/current 100 to 240 V, 50 - 60 Hz, Max. 1.7 A
Power consumption
120 W
Dimensions Approx. 404 Ч 413.5 Ч 419.5 mm (w/h/
d) (16 Ч 16 3 / 8 Ч 16 5 / 8 inches)
Mass Approx. 20 kg (44 lb 1 oz)
Plug and Play DDC1/DDC2B/DDC2Bi
Supplied accessories Power cord (1)
Windows Monitor Information Disk (1)
Warranty card (1)
Notes on cleaning the screen’s surface (1)
This instruction manual (1)
* Recommended horizontal and vertical timing condition
• Horizontal sync width should be more than 1.0 µsec.
• Horizontal blanking width should be more than 3.0 µsec.
• Vertical blanking width should be more than 500 µsec.
Design and specifications are subject to change without notice.
