Specifications
MEASUREMENTS ARE FOR GUIDANCE ONLY. SMALL DIFFERENCES MAY OCCUR
PARAMETER
LITTLE GEM²
LENGTH
98 cms (38.5”)
REAR WIDTH
51 cms (20”)
MAX. USER WEIGHT
113 kg (250 lbs)
BATTERY CAPACITY
12 Ah
MAX SAFE SLOPE
9 degrees at 113 kg (250 lbs)
TURN RADIUS
115 cms (45.3”)
SEAT - BASE HEIGHT
40.5 - 49.5 cms (16”-19.5”)
MAX SPEED
6.4 kph (4 mph)
WHEEL DIAMETER FRONT
17.5 cms (7”)
WHEEL DIAMETER REAR
19 cms (7.5”)
TYRES
Solid
CHARGER OFF-BOARD
1.5 Amps
RANGE
16 km (10 miles)
OVERALL WEIGHT
40 kg (88 lbs)
SEAT WEIGHT
10.4 kg (23 lbs)
BATTERY PACK WEIGHT
9 kg (20 lbs)
DRIVE UNIT WEIGHT
10.7 kg (24 lbs)
HEAVIEST PART (Front Section) 16.8 kg (37 lbs)
FRONT BASKET LOAD MAX
4.5 kg (10 lbs)
GROUND CLEARANCE
6 cms (2.5”)
CONTROLLER (PGDT)
S-DRIVE (Programmable by Dealer)
