System requirements, Package contents, Layout – SIIG II-150 User Manual
Page 2
2
System Requirements
•
Pentium
®
or equivalent PC with an available PCI
slot
•
Windows
®
2000 / XP (32-/64-bit) / Server 2003 &
2008 (32-/64-bit) / Vista (32-/64-bit)
Package Contents
•
SATA II-150 PCI
•
SATA data cable and power cable
•
Spare low profile bracket
•
Driver CD and this quick installation guide
Layout
Figure 1. SATA II-150 PCI Board Layout
Internal
connectors
HDD LED pins (Front chassis LED;
connects vertically)
HDD
Activity LED
