Fuses Usage
ECM/CAM
(3.5L V6 (L66))
Camshaft Sensor, Main Relay
Voltage To PCM, Ignition Coils 1-6
ETC (2.2L Four
Cylinder (L61))
Engine Control Module (ECM),
Electronic Throttle Control
FUEL PUMP Fuel Pump Relay
CIGAR/AUX2 Cigar Lighter
AUX 1 OUTLET Front Auxiliary Power Outlet
FOG LP Fog Lamp Relay
REAR DEFOG Rear Defog Relay
HORN Horn Relay
LH HDLP Left Headlamp
RH HDLP Right Headlamp
INJECTORS
(3.5L V6 (L66))
Fuel Injection
PREM AUD Premium Radio Amplifier
HTD SEATS Heated Seats
Relays Usage
COOL FAN
HIGH
Cooling Fan Motor High
COOL FAN
LOW
Cooling Fan Motor Low
A/C CLUTCH A/C Clutch
PWR WDW
Power Window Switch, Sunroof
Module
FRT WIPER Front Wiper System
RR WIPER Rear Wiper System
WIPER
SYSTEM
Wiper System
ENG MAIN ECM/CAM, EMISS, INJ, ETC
FUEL PUMP Fuel Pump System
DRL Daytime Running Lamps
REAR DEFOG Rear Defog System
HORN Horn
FOG LP Fog Lamps
5-101
