Position a 2.5” SATA hard drive so that the SATA interface is directed
2.
into one of the drive bays, label side up. Gently press the drive inward
until the front panel door begins to close, then lock the drive in place by
closing the door until it clicks shut.
Repeat this procedure to install a second 2.5” SATA drive, into the
remaining bay:
Please note: It is essential that the drive be positioned
properly within the drive bay. Attempting to install a drive
with its interface improperly aligned with the drive bay in-
terface could cause serious damage to both the drive and
the drive bay.
