Begin trigger assembly by pulling wire through slot on trigger(48) as shown.
Complete this assembly by installing trigger to plates with bolt (53) and bolt (58).

Carefully attach cable end to actuator plate (47).

7

42

52

58

66

19 A.

19 B.

48

47

NOTE:
DO NOT OVERTIGHTEN
NUT (42) ONTO BOLT (58).
TRIGGER (48) SHOULD
MOVE FREELY.
