GS110 DIRECT VENT BOILER INSTALLATION AND OPERATION INSTRUCTIONS Page 30
Ref # Name of Part Part # 3 4 5 6 7
Model Size with Item Quantities Below
29 Thermal Switch 59481 1 1 1 1 1
30 Block Assembly 72076 1
72077 1
72078 1
72079 1
72080 1
31 Jacket Bracket 59456 6 6 6 6 6
32 Frame Cross Members 59459 1
59460 1
59461 1
59462 1
59463 1
33 Flue Collector 59427 1
59428 1
59429 1
59430 1
59431 1
34 5/16-18 X 7-1/2" Stud 59392 2 2 2 2 2
35 Flue Collector Clamp 03-1033 1
03-1034 1
03-1035 1
03-1036 1
03-1037 1
36 Drain Filtting PEM CLS-0428-1 59432 1 1 1 1 1
37 Right Base Frame Assembly 72070 1 1 1 1 1
38 Left Base Frame Assembly 72071 1 1 1 1 1
N/S Relief Valve 61988 1 1 1 1 1
N/S Temperature & Pressure Gauge 60265 1 1 1 1 1
See Transformer Primary Harness, P1 76001 1 1 1 1 1
Fig. Transformer Secondary Harness, P2 76002 1 1 1 1 1
20A Control Harness, P3 76003 1 1 1
76004 1 1
Circulator Harness, P4 76004 1 1 1 1 1
HSI Harness, P6 76005 1 1 1 1 1
L1, L2 Harness, P7 76006 1 1 1 1 1
