GS110 DIRECT VENT BOILER INSTALLATION AND OPERATION INSTRUCTIONS Page 29
SERVICE AND REPLACEMENT PARTS LIST
1 Rear, Top, Front & Inner Panels 59450 1
59451 1
59452 1
59453 1
59454 1
2 Left Jacket Side Panel 59495 1 1 1 1 1
3 Right Jacket Side Panel 59496 1 1 1 1 1
4 Gas Valve, White Rodgers 36E65 50064 1 1 1
Gas Valve, White Rodgers 36D27 50065 1 1
5 Blower, Fasco 702110816 55532 1 1 1 1 1
6 Transformer, Honeywell AT140B-1016, 40 VA 51032 1 1 1 1 1
7 Ignition Control, UTC 1013-13B 51196 1 1 1 1 1
8 Pressure Switch .45 WC 55539 1 1 1
.49 WC 55540 1
.54 WC 55541 1
9 Terminal Strip, 2 position 60133 2 2 2 2 2
10 Terminal Strip, 3 position 60134 1 1 1 1 1
11 Gas Tube 59396 1 1 1 1 1
12 Filter 50524 1 1 1 1 1
13 Limit Control, Honeywell L6008A-1242 50524 1 1 1 1 1
14 Burner Box Assembly, NG Orifice 70-1050 1
includes items 15 thru 22 installed 70-1051 1
70-1052 1
70-1053 1
70-1054 1
Burner Box Assembly, LP Orifice 70-1055 1
includes items 15 thru 22 installed 70-1056 1
70-1057 1
70-1058 1
70-1059 1
15 RH Mounting Bracket 03-1006 1 1 1 1 1
16 LH Mounting Bracket 03-1007 1 1 1 1 1
17 Barbed Fitting 61023 1 1 1 1 1
18 Male Connector 1/2" 60861 1 1 1 1 1
19 Compression Spring LC-045H-0 20-1000 1 1 1 1 1
20 Main Gas Orifice, Natural Gas 59434 1
0 - 2000' (consult factory for high altitude) 59514 1
59437 1
59398 1
59399 1
Main Gas Orifice, LP 59433 1
0 - 2000' (consult factory for high altitude) 59515 1
59435 1
59436 1
59516 1
21 O-Ring 06-1002 1 1 1 1 1
22 Blower Outlet Gasket 59499 1 1 1 1 1
23 Ground Rod PSE ME8 50038 1 1 1 1 1
24 Igniter, Norton 601XBM NG 50033 1 1 1 1 1
Igniter, Crystal Tech, LP 16-1000 1 1 1 1 1
25 Flame Sensor, PSE ME7 50037 1 1 1 1 1
26 Spring Clip 59449 3 3 3 3 3
27 Gasket 59497 1 1 1 1 1
28 1/4-20 x 2-1/4" Screw 60824 4 4 4 4 4
Ref # Name of Part Part # 3 4 5 6 7
Model Size with Item Quantities Below
