8



1. WINDOW REQUIREMENTS

• These instructions are for a standard double-hung

window. You will need to modify them for other
types of windows.

• The air conditioner can be installed without the

accordion panels if needed to fit in a narrow
window. See the window opening dimensions.

• All supporting parts must be secured to firm wood,

masonry or metal.

• The electrical outlet must be within reach of the

power cord.

2. STORM WINDOW REQUIREMENTS

A storm window frame will not allow the air
conditioner to tilt toward the outside, and will keep it
from draining properly. To adjust for this, attach a
piece of wood to the stool.

WOOD PIECES WIDTH: 2"
LENGTH:

Long enough to fit inside the window frame.

THICKNESS:

To determine the thickness, place a

piece of wood on the stool to make it 1/2" higher than
the top of the storm window frame.

Attach securely with nails or screws provided by the
installer.





3. REMOVE THE AIR CONDITIONER

FROM

THE CASE

A. Remove the locking screw and locking

bracket from the lower frame. Save to
reinstall later.

B. Remove the ground screw and save to

reinstall later.

C. Slide the air conditioner from the case by gripping the

base pan handle and pulling forward while bracing the
case.

4. PREPARE THE WINDOW

Cut the window sash seal to the proper length. Peel
off the backing and attach the seal to the underside of
the window sash.

Installation Instructions (Continuous)
