– 17 –
ENGLISH
H V
OFF
ON ERROR
POWER
FEED
5-2-2. Loading the Paper
1 Open the cover.
Important!
1. Do not touch the print head imme-
diately after printing as it can be
extremely hot.
2. Do not touch the cutter blade.
· There is a cutter inside the pa-
per outlet slot. Not only should
you not put your hand in the
paper outlet slot while printing
is in progress, never put your
hand into the outlet even when
printing is not in progress.
2 Cut off the front edge of the roll
paper perpendicularly.
3 Confirm that the power of the printer
is turned on.
4 While observing the direction of the
roll, set the paper roll into the hol-
low as shown in Fig. 5-13.
Fig. 5-12 Removing the cover
Cover
H
V
OFF
ON
ERROR
POWER
FEED
Fig. 5-13 Setting the paper
Roll paper
