15 GB
Gettin
g
Sta
rted
Connecting a component to the COAXIAL DIGITAL 2 IN jack
• The OPTICAL TV IN jack has priority when you connect both the audio output of the TV to the OPTICAL TV IN
and AUDIO IN jack of the system.
Note
ANTENNA
AM FM
75 COAXIAL
HDMI TV OUT SAT/CATV IN DVD IN BD IN
EZW-T100
SPEAKER
ONLY FOR SS-FS3
R
L
DMPORT
DC 5V
0.7A MAX
AUDIO IN
R
TV
L
OPTICAL
TV IN
COAXIAL
DIGITAL
DIGITAL 1 IN DIGITAL 2 IN
TV monitor, projector, etc.
A
A Audio cord (not supplied)
B Digital optical cord (supplied)
C Digital coaxial cord (not supplied)
Video signal
: Signal flow
C B
or
Audio signal Video signal Audio signal
DVD player (recorder),
satellite/cable television tuner, etc.
Video signal
Rear of the
subwoofer
