The connector of the speaker cords is color-coded depending on the type of speaker.
Connect the speaker cords to match the color of the SPEAKER jacks of the subwoofer.
Connecting the speakers
ANTENNA
AM FM
75 COAXIAL
HDMI TV OUT SAT/CATV IN DVD IN BD IN
EZW-T100
SPEAKER
ONLY FOR SS-FS3
R
L
DMPORT
DC 5V
0.7A MAX
AUDIO IN
R
TV
L
OPTICAL
TV IN
COAXIAL
DIGITAL
DIGITAL 1 IN DIGITAL 2 IN
Speaker (R) Speaker (L)
Red (speaker (R))
Rear of the
subwoofer
White (speaker (L))
